| Electrical Characteristics | |
|---|---|
| Supply Voltage | +5VDC, ±10% |
| Current Consumption | 15 mA |
| Output Voltage @ Imax, R=10KΩ @ 25°C | 2.5(50%) ± 2(40%)* (I/Imax) |
| Accuracy @ Ta = 25°C | ±0.5% |
| Linearity | <0> |
| (Excluding Electrical Offset) Output Offset Voltage @ 0A | < ±25mV |
| Frequency Bandwidth (-3dB) | DC -150 KHz |
| Primary Nominal Current | Any Current Rating |
| RMS Current | From 20 to 600A |
| Mechanical Characteristics | |
|---|---|
| Ambient Operating Temprature | -40°C to +85°C |
| Ambient Storage Temprature | -40°C to +85°C |
| Mass | 60gm |
