| Supply Voltage | ±15 VDC, ±10% |
| Current Consumption | <20mA |
| Output Voltage @ Imax, R=10KΩ @ 25°C | ± 4 VDC |
| Accuracy @ Ta = 25°C | ±1% |
| Linearity | <±1% of Imax |
| (Excluding Electrical Offset) Output Offset Voltage @ 0A | < ±10mV |
| Frequency Bandwidth (-3dB) | 25 kHz |
| Insulation resistance @500 VDC | >1000 MΩ |
| Load Resistance | >5 KΩ |
| Electrical Offset Voltage, @ 25 °C | < 10 mV |
| Hysteresis Offset Voltage@ Ip = 0,after RMS current limit | < ±10 mV |
| Temperature coefficient of VOE, SCHACS-15 | < ±2 mV/K |
| Temperature Coefficient of VOUT (% of reading) | < ±0.1 %/K |
| Step response time to 90% of RMS current limit | < 5 uSec |
| Ambient Operating Temperature | -10°C to +80°C |
| Ambient Storage Temperature | -25°C to +80°C |
| Mass | 1700gm |
