| Std. Resistance Range | 200 to 200KΩ |
| Power Rating | 5 Watt @ 40 °C. |
| Linearity | Std. ± 0.5%, Special ± 0.25% |
| Insulation resistance | 1000 M Ω at 500 VDC. |
| Maximum Working Voltage | 1000 VDC. |
| Voltage proof | 3000 VAC for 1 min. at sea level. |
| Electrical Angle of Rotation | 3600° + 10°/-0° |
| Resistance tolerance | Std.± 5%, other on request. |
| End Resistance | 2Ω or %Lin. Whichever is greater |
| Mounting | Bush mounting |
| Mechanical Angle of Rotation | 3600° + 10°/-0° |
| Temp. range | 0° to 70°C |
| Housing, bearing and back lid | Thermo Plastic housing with Nickel plated brass bush |
| Spindle | Extruded Brass 10/15 mm |
| Terminals, Wiper Contact | Special alloys |
| Low TCR Resistance wire. Maximum TCR of ± 150 ppm/°C | |
