| Std. Resistance Range | 100 to 20KΩ |
| Power Rating | 1 Watt @ 40 °C |
| Standard Resistance Values | 100, 250, 500, 1K, 2K, 5K, 10K, 20K |
| Standard Resistance Tolerance | 5 %, Other on request |
| Linearity | ± 1% |
| Insulation resistance | 1000 M Ω at 500 VDC |
| Maximum Working Voltage | 100 VDC |
| Voltage proof | 750 VAC for 1 min. at sea level |
| Electrical Angle of Rotation | 300° + 2°/-2° |
| Mechanical Angle of Rotation | 330° + 2°/-2° |
| End Resistance | 2Ω or %Lin. Whichever is greater |
| Rotational Life Expectancy | 2,50,000 Cycles |
