| Electrical Characteristics | |
|---|---|
| Supply Voltage | +5VDC, ±10% |
| Current Consumption | 15 mA |
| Accuracy @ Ta = 25°C | ± 2% |
| Linearity | <1> |
| (Excluding Electrical Offset) Output Offset Voltage @ 0A | < ±40mV |
| Frequency Bandwidth (-3dB) | DC -100 KHz |
| Primary Nominal | Any Current Rating |
| RMS Current | From 100 to 1500A |
| Mechanical Characteristics | |
|---|---|
| Ambient Operating Temprature | -40°C to +85°C |
| Ambient Storage Temprature | -40°C to +85°C |
| Mass | 300gm |
