| Std. Resistance Range | 100 to 100KΩ |
| Power Rating | 2 Watt @ 40 °C |
| Linearity | Standard ± 0.5%, ± 0.25% on request |
| Insulation resistance | 1000 M Ω at 500 VDC |
| Maximum Working Voltage | 250 VDC |
| Voltage proof | 750 VAC for 1 min. at sea level |
| Electrical Angle of Rotation | 3600° + 10°/-0° |
| Resistance tolerance | Std.± 5%,other on request |
| End Resistance | 2Ω or %Lin. Whichever is greater |
| Mounting | Bush mounting |
| Mechanical Angle of Rotation | 3600° + 10°/-0° |
| Temp. range | 0° to 70°C |
| Housing, bearing and back lid | Reinforced Engineering Plastic with Nickel plated brass bush |
| Spindle | Extruded Brass 10/ 15 mm |
| Terminals, Wiper Contact | Gold plated |
| Low TCR Resistance wire. | |
